1060 Aluminum Alloy Overview

Al content of 1060 aluminum alloy is 99.6%, which is a typical representative of pure aluminum alloy series. so, 1060 alloy has good plasticity, corrosion resistance, electrical and thermal conductivity, etc., as well as high elongation, tensile strength, formability, easy to withstand various pressure processing, stamping, stretching and bending, etc. 1060 aluminum alloy can fully meet the conventional processing requirements.

Here, Mingtai Al. produces quality hot-rolled 1060 aluminum alloy sheet, the widest width can reach 2650 mm, the thickest thickness can reach 500 mm. Mingtai Al. is one of the few manufacturers of ultra-wide and ultra-thick plates in China. so Mingtai 1060 aluminum alloy is widely used in aluminum bus duct, wide curtain wall panels, automobile heat shields, aluminum composite panels(ACP), soft power battery connections, and face mask nose wire, food packaging, auto parts, lamps, signage, nameplates, etc. So far, Mingtai Al. has been focusing on the production of hot-rolled ultra-wide 1060 aluminum alloy sheets for 23 years, with mature technology, complete equipment, and guaranteed product quality! This is Mingtai Al., Looking forward to your purchase!Technical Parameters of 1060 Aluminum Alloy
1060 Aluminum Alloy

Advantages of 1060 Aluminum Alloy

  • Excellent processability, High corrosion resistance, Good weldability and electrical conductivity
  • Flat version, High error accuracy, Internal stress eliminated, No deformation during cutting
  • High gloss on the surface, Good alkaline washing effect, can reach level A in the water brushing test
  • Mature production technology,1060 aluminum alloy price has a huge advantage

1060 Aluminum Alloy

Technical Parameters of 1060 Aluminum Alloy

Grade Temper Specification (mm) Enquiry Typical Usages Standard
1060 O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H112,etc. Thickness Width Length
0.016-0.2 100-1600 C enquiry Aluminum busduct, Aluminum composite panels (ACP), Wide curtain wall, Signage,etc EN/ ASTM/ GB
0.10-0.45 100-2500 C enquiry
0.20-500 100-2650 500-16000 enquiry

1060 Aluminum Alloy

Chemical Composition of 1060 Aluminum Alloy

Grade Si Cu  Mg Mn Zn Ti V Fe Other Al
1060 0.25 0.05 0.03 0.03 0.05 0.03 0.05 0.35 Single Total 99.6
0.03

Mechanical Properties of 1060 Aluminum Alloy

Grade Tensile Strength Rm/Mpa Yield Strength Rp0.2/Mpa Elongation/% Hardness/ HBWα
1060 110-136 75 3-5 33

Leave a inquiry

Please help to confirm alloy number and temper, size (thickness*width*length), quantity at your demand.
