5754 Aluminium Alloy

5754 aluminium alloy belongs to non-heat treatable 5000 series Al-Mg family. So aluminium 5754 properties show excellent tread and anodizing quality, weldability, orrosion resistance especially to seawater, some chemical and polluted industrial environment. Besides, al 5754 mechanical properties are prominent in wrought aluminium. Such as tensile strength of 220 – 270 MPa. Therefore, 5754 aluminum alloy is widely used for marine, vehicle components, auto parts, welded structures, food industry, construction field, etc.

5754 aluminium alloy

Aluminium 5754 Properties

Weldability: for example, 5754 aluminium alloy has excellent weldability such as Gas welding, Arc, Resistance, Brazability and so on.

Corrosion and Rust Resistance: similarly, 5754 aluminum alloy is also often referred to as marine grade aluminum. And this because it has good seawater and atmospheric corrosion resistance.

Cold Workability: as non-heat treated alloy, 5754 aluminium alloy can be well cold worked to produce tempers with a higher strength but a lower ductility.

5754 aluminium alloy

Al 5754 Mechanical Properties

Alloy & Temper Proof Stress Tensile Strength Elongation A50 mm Hardness Brinell
Al 5754 h111 60 Min MPa 160 – 200 MPa 12 Min % 44 HB
Al 5754 h114 80 Min MPa 190 – 260 MPa 12 Min % 52 HB
Al 5754 h22 130 Min MPa 220 – 270 MPa 7 Min % 63 HB
5754 h24 160 Min MPa 240 – 280 MPa 6 Min % 70 HB

5754 Aluminum Alloy Applications

In fact, 5754 aluminium alloy is very versatile material. For example, due to its excellent corrosion resistance, it work well in marine applications. Besides, plus its good weldability, it becomes inseparable alloy in construction industry. In addition, good anodizing quality 5754 alloy also is suitable for decorative anodizing.
Specifically, 5754 aluminum alloy is widely used in tread plate, welding structure, ship structure and marine facilities, vehicle components, food processing, storage tank trailer, pressure vessel, rivets, window internal and so on.

5754 aluminium alloy

Technical Parameters of Mingtai 5754 Aluminum Alloy

Grades: 5754 aluminium alloy
Alloy component mass fraction: Mg : 2.6-3.6, Si: 0.4, Fe: 0.4, Cu :0.1, Mn: 0.5, Cr: 0.3, Zn : 0.2, Ti: 0.15, Others: 0.05, Al: 94.2 to 97.4%
Temper: O, H14, H1*, H111, H114, H11*, H22, H24, H2*, H3*, etc.
Types: sheet, plate, tread plate ( big/ small 5 bars/ Quintet, diamond/ single bar, etc.), coil
Thickness: 0.2mm-500mm
Width: 100mm-1650mm
Length: Customizable
Standard: ASTM B209, EN AW, DIN, etc.
Mingtai Quality: International quality standard, stable performance, clean surface, no oil, black spots, bright lines, scratches, flat shape, no burr, crimping, etc. And provide original factory warranty!

Leave a inquiry

Please help to confirm alloy number and temper, size (thickness*width*length), quantity at your demand.
