4017 Aluminum Tread Plate
Sample： A4 Sized
Payment Terms： L/C,D/P,T/T
Delivery time： Within 15-30 Days
Email Us:sale06@mingtai-al.com
4017 Aluminum Tread Plate for Sale
4017 aluminum tread plate is equivalent to a 3003 aluminum tread plate in many respects. for example, the corrosion resistance of the 4017 tread plate is the same as 3003 Grade, and with a bright finish tread surface also similar to 3003 aluminum tread plate,etc., although the 4017 is registered in EN 573-3 as 4017. In practice, 4017 aluminum tread plate is widely used for building, vehicles, transportation, manufacturing, architectural applications, all aspects. It’s highly practical and decorative, also has strong durability, skid resistance, formability, processability, weldability, etc.
Features of 4017 Aluminum Tread Plate
- Corrosion Resistance.According to field tests, 4017 aluminum tread plate exhibits outstanding effect, and similar results as standard 3 series alloys.
- Surface Treatment. High surface gloss, clear and three-dimensional pattern.
- Weldability.4017 aluminum tread plate can be well welded by MIG, TIG, LASER ad high frequency methods.
Applications of 4017 Aluminum Tread Plate
In general, 4017 aluminum tread plate works where good strength and formability is required. Such as walkways, cabinet making, other decorative assemblies in architectural structures, and truck bed, toolbox, ducting, etc.
Specifically, 4017 aluminum tread plates are widely used for wainscot of garage/ gym/ canteen/ office,etc., as well as interior/ floor of vehicles/ boats, catwalk non-slip floor, roofing, cladding systems, sign making and so on.
Mechanical Properties of 4017 Aluminum Tread Plate
| Temper | Proof (MPa) | UTS (MPa) | % Elongation | Bend Radius | |
| (min) | (90°bend) | (180°bend) | |||
| H16 | 150 | 175-225 | 2% | %T | 2T |
| H18 | 180 | 200-265 | 2% | 1T | 2%T |
| H44 | 110 | 140-185 | 4% | 0T | 1T |
| H46 | 150 | 175-225 | 2% | %T | 2T |
| H48 | 180 | 200-265 | 4% | 1T | 2%T |
Physical Properties of 4017 Aluminum Tread Plate
| Property Value Unit | Value | Unit |
| Density at 20℃ | 2.72 | g / cm3 |
| Melting Range | 560-640 | ℃ |
| Thermal Capacity | 900 | J / kg℃ |
| Thermal Conductivity | 200 | W / m℃ |
| Thermal Expansion | 23×10-6 | / ℃ |
| Resistivity at 20℃ | 32 | nΩm |
| Modulus of Elasticity | 70 | GPa |
| Modulus of Rigidity | 27 | GPa |
Technical Parameters of 4017 Aluminum Tread Plate
| Elements | Si | Fe | Cu | Mn | Mg | Zn | Al | |
| Min (%) | 0.6 | – | 0.1 | 0.6 | 0.1 | – | Remain | |
| Max (%) | 1.6 | 0.7 | 0.5 | 1.2 | 0.5 | 0.2 | Remain | |
| Typical alloy | 4017 Aluminum Tread Plate | |||||||
| Patterns Types | Diamond/ Single bar, Big 5 bars, Small 5 bars, 3 bars, 2 bars | |||||||
| Material temper | H16, H18, H22, H112, H321, H32, H44, H46, H48, etc | |||||||
| Thickness(mm) | 0.8-7.0 | |||||||
| Width (mm) | 20-2650 | |||||||
| Length (mm) | Customize | |||||||
| Typical Usages | Anti-skid floor, Walkways, Truck bed, Tool box, Cabinet making, Wainscot, etc | |||||||
4017 Aluminium Checker Plate Suppliers and Price
There are abundant 4017 aluminum tread plates in various thicknesses, customizable sizes, and rich patterns. Here, Mingtai as one of large 4017 aluminum checker plate suppliers, is the second reputable export manufacturer of aluminum sheet/coil/foil in the Americas. And our 4017 aluminum tread plate shows clear surface pattern, high gloss and no oil stains, scratches and other defects. In a word, Superior performance, high quality, and to provide global users with quality assurance!
Of course, the Mingtai aluminum tread plate price is very cost-effective as an advantage! so, if you are looking for aluminium checker plate products, then don’t hesitate to contact us! Just send an e-mail or click online customer service, we will quickly provide a satisfactory quotation for you! Come on!
