Aluminum Honeycomb Sheet in Singapore

Loading Port: Tianjin/Qingdao, China
Sample: A4 Sized
Payment Terms: L/C,D/P,T/T
Delivery time: Within 15-30 Days
Email Us:sales01@mingtai-al.com
Contact Us

Aluminum Honeycomb Sheet in Singapore Hot Sale:

Aluminum honeycomb sheets in Singapore with quality and the preferential price is on sale. In practice, an aluminum honeycomb sheet is an important component material of the honeycomb composite panel. Such as 0.4mm-3.0mm 3003-H24 aluminum sheet for the upper/ lower bottom plates, and 0.02~0.06mm 3003 aluminium foil for honeycomb core, etc. As for the aluminum honeycomb composite panel, we all know it’s the perfect building material for curtain walls, construction exterior walls, traffic vehicles, interior partitions, etc. So, aluminum honeycomb sheet in Singapore has highly practical. It’s very hot-selling!
Honeycomb foil

Alloy of Aluminum Honeycomb Sheet in Singapore Practicalities:

3003 Aluminum Honeycomb Sheet in Singapore:

Specific Application
For the upper/ lower bottom plates: 0.4mm-3.0mm thick 3003-H24 aluminum sheet is on sale.
For honeycomb core: 0.02~0.06mm thick 3003 h18 aluminum sheet foil is hot-selling.
Element of 3003 Aluminum Honeycomb Sheet in Singapore

Grade Mn Mg Si Fe Cu Cr Zn Other Al
Single Total
3003 1.0~1.5 0.6 0.7 0.05~0.20 0.1 0.1 0.2 Remain

Mechanical Properties

Alloy Denisty Tensile Strength Yield Strength
Grades 3003 2.73g/cm3 115 {σb(MPa)} ≥85 {σ0.2(MPa)}

Features of 3003 Aluminum Honeycomb Sheet in Singapore
3003 aluminum honeycomb sheet in Singapore is a typical 3 series anti-rust Al-Mn aluminum alloy. So 3003 aluminum sheet foil for honeycomb panel exhibits high gloss, sufficient strength, outstanding surface treatment effect, excellent processing, corrosion, and weather resistance. Besides, due to the addition of main alloy Mn, reduce the welding clearance, showing the best weldability.
honeycomb foil 3003

5052 Aluminum Honeycomb Sheet in Singapore:

Specific Application
For the upper/ lower bottom plates: 0.4mm-3.0mm thick 5052-H14 aluminum sheet is also available.
For honeycomb core: 0.02~0.06mm thick 5052 h18 aluminum sheet foil can be better.
Element of 5052 Aluminum Honeycomb Sheet in Singapore

Grade Mg Mn Si Fe Cu Cr Zn Other Al
Single Total
5052 2.2-2.8 0.1 0.25 0.4 0.1 0.15-0.35 0.1 0.05 0.1 Remain

Mechanical Properties

Alloy Denisty Tensile Strength Conditioned Yield Strength
Grades 5052 2.68g/cm3  173~244 {σb(MPa)} ≥70 {σ0.2(MPa)}

Features of 3003 Aluminum Honeycomb Sheet in Singapore
As we know, the comprehensive performance of 5052 aluminum sheet is better than that of 3003 Grade. So that’s why 5052 aluminum honeycomb sheet in Singapore will be slightly expensive. However, 5052 aluminum foil sheet does have an amazing effect on honeycomb panels. Such as excellent corrosion and weather resistance, high strength, better mechanical properties, etc
honeycomb foil 3003

Mingtai Aluminum Honeycomb Sheet in Singapore:

Of course, our aluminum honeycomb sheet in Singapore is also available in various specifications for your choice. And if you have special demands, we also can customize production. So far, Mingtai Aluminum as a large aluminum sheet manufacturer has enjoyed a high reputation throughout the Southeast Asian market. And you can easily find our aluminum honeycomb sheet in Singapore with the “ Mingtai ”logo. The following specifications are for your choice! Come to contact us!

Alloy Series Typical Grades Material Temper Thickness Width Length
3 series Al-Mn Alloy 3003 O, H14, H16, H18, H22, H24,etc 0.02-3.0mm 100-1650mm C
5 series Al-Mg Alloy 5052 0.02-3.0mm 100-1650mm C

Leave a inquiry

Please help to confirm alloy number and temper, size (thickness*width*length), quantity at your demand.
